When people talk about wheels and tires, one of the most common terms you may hear is bolt pattern. The bolt pattern tells you how many lug holes a wheel has and how far apart they are. For Ford vehicles, one famous size is the 5×5.5 bolt pattern.
This pattern has been around for many years and is still very popular today. Many trucks, SUVs, and classic Ford models use it. In this article, we will explain what the 5×5.5 bolt pattern means, which Ford vehicles use it, why it matters, and how you can measure it. We will also share facts, figures, and a table to make it easy to understand.
What Does 5×5.5 Bolt Pattern Mean?
A bolt pattern is written in two numbers. The first number tells you how many bolt holes are in the wheel. The second number tells you the diameter of the circle that goes through the center of all the bolt holes.
- In 5×5.5, the number 5 means there are 5 bolt holes.
- The 5.5 means the distance across the circle of those holes is 5.5 inches.
So, a 5×5.5 wheel has five lug holes set on a circle that is 5.5 inches wide. This pattern is also sometimes written as 5×139.7mm because 5.5 inches equals 139.7 millimeters.
Which Ford Vehicles Use the 5×5.5 Bolt Pattern?
The 5×5.5 bolt pattern has a long history with Ford. It has been used on many trucks and SUVs, especially older models.
Here are some Ford vehicles that used or still use the 5×5.5 bolt pattern:
- Ford F-100 (up to 1986 models)
- Ford F-150 (up to 1996 in some trims)
- Ford Bronco (1966–1996)
- Ford E-Series vans (older models)
- Ford Excursion (early years)
This pattern was very common in full-size Ford trucks for decades. It gave strength, stability, and made it easier for these heavy-duty vehicles to carry big loads.
Why Is the 5×5.5 Bolt Pattern Important?
The bolt pattern is very important for safety and performance. If you try to put wheels with the wrong bolt pattern on your Ford, they will not fit properly. That can lead to:
- Loose wheels
- Damage to the wheel studs
- Shaking and vibration while driving
- Safety risks like wheels coming off
That’s why knowing your exact bolt pattern, like the 5×5.5, is critical when buying new wheels or replacing old ones.
Facts and Figures About the 5×5.5 Bolt Pattern
Here are some important details about this bolt pattern:
- Bolt count: 5 lugs
- Bolt circle diameter: 5.5 inches (139.7 mm)
- Common thread size: 1/2″-20 or 9/16″-18 depending on the year/model
- Center bore size: Usually 108 mm (varies by wheel brand)
- Torque specification: Between 95–150 ft-lbs depending on the vehicle
How Do You Measure the 5×5.5 Bolt Pattern?
If you are not sure about your wheel’s pattern, you can measure it. Here’s how to check a 5-lug wheel like 5×5.5:
- Count the number of bolt holes – there should be 5.
- Take a ruler or caliper.
- Measure from the center of one lug hole to the outer edge of the lug hole directly across (skip one hole since there are 5).
- If the measurement is 5.5 inches, then you have a 5×5.5 pattern.
This simple check can save you from buying the wrong wheels.
Ford and Other Brands Using 5×5.5
Ford is not the only company that uses this bolt pattern. Many other brands also use 5×5.5 because it became a standard size in the truck and SUV world.
Some examples include:
- Dodge Ram 1500 (up to 2010)
- Jeep CJ models
- Suzuki Samurai
This means there are many wheel options available on the market if you have a Ford with this bolt pattern.
Table: Ford Vehicles with 5×5.5 Bolt Pattern
| Ford Model | Years Used | Bolt Pattern | Notes |
|---|---|---|---|
| Ford F-100 | Up to 1986 | 5×5.5 (139.7mm) | Classic trucks, popular with restorers |
| Ford F-150 | Up to 1996 (some trims) | 5×5.5 (139.7mm) | Full-size truck, strong build |
| Ford Bronco | 1966–1996 | 5×5.5 (139.7mm) | Off-road favorite |
| Ford E-Series Van | Older models | 5×5.5 (139.7mm) | Heavy-duty vans |
| Ford Excursion | Early models | 5×5.5 (139.7mm) | Large SUV |
Advantages of the 5×5.5 Bolt Pattern
The reason the 5×5.5 bolt pattern lasted so long in Ford vehicles is because of its strength and versatility. Some advantages include:
- Durability: It handles heavy loads well.
- Stability: Wider spacing improves wheel strength.
- Aftermarket support: Many wheel designs are available.
- Cross-compatibility: Fits some Dodge and Jeep wheels.
Things to Watch Out For
While 5×5.5 is reliable, there are a few things you need to watch out for:
- Always check hub bore size to make sure the wheel fits snugly.
- Use the correct lug nuts (conical or flat seat).
- Double-check torque settings after installing wheels.
- Some newer Ford trucks switched to different patterns, so do not assume all Fords use 5×5.5.
Conclusion
The 5×5.5 bolt pattern Ford has played a big role in the history of Ford trucks and SUVs. From the classic F-100 to the powerful Bronco, this bolt pattern helped give these vehicles strength, safety, and reliability. With 5 lugs set on a 5.5-inch circle, it remains one of the most recognized patterns in the truck world. Knowing about bolt patterns helps you choose the right wheels, avoid safety issues, and keep your Ford running smoothly.
If you own an older Ford truck or Bronco, chances are your wheels use the 5×5.5 bolt pattern. With so many aftermarket options available, you can upgrade your vehicle’s look and performance while keeping it safe on the road.
